Removable PC Module
Thanks to the modular design, the PC module can be removed and used as a Box PC; platform upgrades and servicing can be done without replacing the display.
1 / 8
E-Life Solutions
With a 15.6” Full HD true-flat touchscreen, an IP65 front panel and a removable PC module, the E-Life EPC-816 is a next-generation Panel PC offering flexible use in both industrial and commercial settings. With Intel Alder Lake-N and Meteor Lake processor options, an integrated 5 MP camera and POS interfaces, it is ready for self-service and point-of-sale applications.
E-Life EPC-816 Panel PC 15.6” Full HD true-flat PCAP touchscreen Intel N95 / i3-N305 or Core Ultra 5 125U IP65 front panel, modular PC design 4 × USB 3.0 + 2 × USB 2.0, dual Gigabit LAN 5 MP integrated camera, optional MSR Wide 12–48V DC input, optional PoE
Thanks to the modular design, the PC module can be removed and used as a Box PC; platform upgrades and servicing can be done without replacing the display.
The front panel of the 15.6" Full HD (1920 × 1080) true-flat PCAP display is IP65 protected and easy to clean in kitchens and sales areas exposed to dust and splashes.
Configured with Intel N95 / Core i3-N305 (Alder Lake-N) or Core Ultra 5 125U (Meteor Lake) options, 4 GB / 8 GB memory and a 128 GB / 256 GB SSD.
A 5 MP integrated camera, optional 3-track MSR card reader and 3W built-in speaker bring ordering, payment and identity verification steps together in one device.
2 × Powered USB 12V, 1 × Powered USB 24V, an RJ11 cash drawer port and 3 × RS232 (RJ48) with selectable voltage power printers and peripherals directly.
Wide 12–48V DC input and optional PoE 802.3bt support can reduce the need for a separate power line at the installation point.
Its 388 × 249 × 47 mm size and 3.5 kg weight save space on narrow counters and desktop ordering points.
Support for Windows 10 IoT Enterprise, Linux and Android 13 fits different POS and kiosk software ecosystems with the same hardware.
Optional Wi-Fi 6 + Bluetooth 5.2, USB-C (DP/PD) and an optional second LAN provide installation flexibility at retail and hospitality sites.
The EPC-816 is offered under E-Life Solutions, Noya Tech’s own brand. Our technical team supports selection of the processor module, operating system and POS peripherals as well as software integration; with experience gained since 1994, we provide assembly, testing and technical service in Türkiye.
Over 30 years of experience and a broad product range.
Assembly, testing and after-sales service in a 2,500 m² facility.
ISO 9001 quality and ISO 27001 information security.
Get pricing and lead time information for E-Life EPC-816 Panel PC.
| Platform | |
|---|---|
| Processor | Intel N95 / Core i3-N305 (Alder Lake-N) or Core Ultra 5 125U (Meteor Lake) |
| Memory | 4 GB / 8 GB DDR4 or DDR5 (depending on platform) |
| Storage | 128 GB / 256 GB M.2 SSD |
| Operating System | Windows 10 IoT Enterprise, Linux, Android 13 |
| Modular Design | Can be converted into a Box PC with the removable PC module |
| Display & Touch | |
| Display | 15.6” TFT LCD |
| Resolution | 1920 × 1080 Full HD |
| Touch | True-Flat PCAP multi-touch |
| Front Panel | IP65 dust and splash resistant |
| Integrated Hardware | |
| Camera | 5 MP integrated camera |
| Card Reader | 3-track MSR (USB, optional) |
| Audio | 1 × 3W built-in speaker |
| Connections | |
| LAN | Gigabit Ethernet (optional second LAN) |
| Serial Port | 3 × RS232 (RJ48, 0V / 5V / 12V selectable) |
| USB | 2–4 × USB 3.0 and 2–4 × USB 2.0 depending on platform |
| USB Type-C | 1 × USB-C (DP/PD) |
| POS Interfaces | 2 × Powered USB 12V, 1 × Powered USB 24V, cash drawer (RJ11) |
| Wireless | Optional Wi-Fi 6 + Bluetooth 5.2 |
| Mechanical & Power | |
| Power | 65W/19V adapter (120W optional), wide 12–48V DC input, optional PoE 802.3bt |
| Mounting | VESA 75 × 75 / 100 × 100 |
| Dimensions | 388 × 249 × 47 mm |
| Weight | 3.5 kg |
| Operating Temperature | 0 ~ 40 °C |
| Humidity | 20% ~ 85% RH (non-condensing) |
| Certificate | CE Class B, FCC Class B, LVD |
No specifications match your search.
With its IP65 front panel, integrated camera and POS interfaces, the EPC-8xx series is used in both industrial and commercial self-service areas.
No datasheet, catalog or user manual has been added for this product yet. You can request the latest documents from our team by citing the product name.
Contact UsThe E-Life EPC-816 Panel PC comes with a 5-year warranty, providing peace of mind for your long-term projects.
Email: info@noyatech.com
Phone: +90 850 399 66 92
Phone: +90 212 294 24 03
Our expert team is here to help with product selection, installation and integration questions. You can request the latest brochure, technical drawings and user manual from our team by quoting the product code.
It is compatible with Windows 10 IoT Enterprise, Linux and Android 13.
It supports VESA 75 × 75 and 100 × 100 mounting standards.
It operates at 0 ~ 40 °C ambient temperature with a wide 12–48V DC input range and optional PoE 802.3bt power.
Yes, the IP65 front panel protects against dust and water splashes.
The PC module can be removed and replaced, simplifying maintenance, and the module can be used as a Box PC when needed.
