i5-8500T or i7-8700T Option
8th Gen Intel Core i5-8500T (up to 3.50 GHz) or i7-8700T (35W) processor options on the LGA 1151 socket and the Intel Q370 chipset let you choose performance based on your needs.
1 / 4
E-Life Solutions
The E-Life Inno-Box EX-8 Series is a field-proven, desktop-class Box PC platform offering 8th Gen Intel Core i5-8500T and i7-8700T processor options on the LGA 1151 socket, the Intel Q370 chipset and a fanless aluminum enclosure. With triple display output, RAID-capable drive bays and Digital I/O, it is used in industrial automation and imaging projects.
E-Life Inno-Box EX-8 Series 8th Gen Intel Core i5-8500T / i7-8700T (LGA 1151) 8 GB DDR4 2400 MHz memory, 128 GB SATA III M.2 SSD Optional 2 × 2.5” removable drive bay, RAID 0/1/5/10 2 × Intel Gigabit LAN (i219LM, i211AT) 1 × HDMI, 1 × DP, 1 × VGA; 4 × USB 2.0, 3 × USB 3.0, 1 × USB 3.1 Type-A 4 inputs / 4 outputs Digital I/O, fanless aluminum enclosure
8th Gen Intel Core i5-8500T (up to 3.50 GHz) or i7-8700T (35W) processor options on the LGA 1151 socket and the Intel Q370 chipset let you choose performance based on your needs.
8 GB of DDR4 2400 MHz SODIMM memory can be expanded up to 32 GB; it runs Windows 10 IoT or Windows 10 Pro on a 128 GB M.2 SSD.
The optional 2 × 2.5” HDD/SSD bay is externally accessible and lockable; Intel SATA RAID 0/1/5/10 support ensures data continuity in recording systems.
Intel UHD Graphics 630 with HDMI, DP and VGA outputs lets a single device drive an operator display, monitoring board and reporting screen.
With 2 × Intel Gigabit LAN, RS232/422/485 + RS232, 8 USB ports including USB 3.1 Type-A, and 4-in/4-out Digital I/O, it connects directly to field devices.
The fanless aluminum enclosure, 0 ~ 60 °C operating range and 12–24V DC power input ensure reliable operation in environments with heavy dust and vibration.
Offering i5 and i7 options with the same enclosure and I/O layout makes it easy to establish a common hardware standard across lines with different performance requirements.
A desktop-class processor, triple display and RAID storage provide a solid foundation for quality control, data acquisition and video recording applications.
The fanless design and externally accessible drive bays reduce maintenance needs and allow quick drive replacement in the field.
The Inno-Box EX-8 Series is offered under E-Life Solutions, the registered brand of Noya Tech. We work with you to choose i5 or i7 and define the memory and storage configuration for your application, then assemble and test it at our 2,500 m² facility and support it with technical service in Türkiye.
Over 30 years of experience and a broad product range.
Assembly, testing and after-sales service in a 2,500 m² facility.
ISO 9001 quality and ISO 27001 information security.
Get pricing and lead time information for Inno-Box EX-8 Series.
| Platform | |
|---|---|
| Processor | Intel Core i5-8500T (up to 3.50 GHz) or i7-8700T, 35W |
| Chipset | Intel Q370 |
| Memory | 8 GB DDR4 2400 MHz SODIMM (max. 32 GB) |
| Storage | 128 GB SATA III M.2 SSD |
| Operating System | Windows 10 IoT, Windows 10 Pro |
| Storage & Expansion | |
| Drive Bay | Optional 2 × 2.5” HDD/SSD, externally accessible, lock-protected |
| RAID | Intel SATA RAID 0/1/5/10 |
| SATA | 3 × SATA 6Gb/s |
| Expansion | 1 × M.2 (Wi-Fi and 4G) |
| Connections | |
| LAN | 2 × Intel Gigabit LAN (i219LM, i211AT) |
| Serial Port | 1 × RS232/422/485, 1 × RS232 |
| USB | 4 × USB 2.0, 3 × USB 3.0, 1 × USB 3.1 Type-A |
| Digital I/O | 4 inputs / 4 outputs |
| Video Output | 1 × HDMI, 1 × DP, 1 × VGA (triple display) |
| Graphics | Intel UHD Graphics 630 |
| Audio | Realtek HD Audio |
| Mechanical & Power | |
| Enclosure | Aluminum, fanless |
| Power Input | 12–24V DC, external power on/off button connector |
| Adapter | 12V/10A 120W |
| Dimensions | 326 × 192 × 84 mm |
| Weight | 4 kg |
| Operating Temperature | 0 ~ 60 °C |
No specifications match your search.
The Inno-Box EX series delivers desktop-class Intel Core processors in a fanless, rugged enclosure for industrial applications that demand high processing power.
E-Life Inno-Box EX-8 Series comes with a 5-year warranty, providing assurance for your long-term projects.
Email: info@noyatech.com
Phone: +90 850 399 66 92
Phone: +90 212 294 24 03
Our expert team is here to help with product selection, installation and integration questions. You can request the latest brochure, technical drawings and user manual from our team by quoting the product code.
Compatible with Windows 10 IoT and Windows 10 Pro.
It can be placed on a desk or inside a cabinet; contact our team about mounting options.
Operates at 0 ~ 60 °C ambient temperature with 12–24V DC input.
Yes, Intel SATA RAID 0/1/5/10 is supported with the optional 2 × 2.5” drive bay.
