10-Core Intel Core i5-1235U
The 12th Gen Intel Core i5-1235U (10 cores, up to 4.40 GHz, 12 MB cache) and Intel Iris Xe Graphics deliver high multi-core performance for edge applications.
1 / 6
E-Life Solutions
The E-Life Inno-Box G3 1235U is the next-generation model of the compact Inno-Box family, featuring a 12th Gen Intel Core i5-1235U ten-core processor, an NVMe SSD and a wide -20 ~ +60 °C operating temperature. With six serial ports, 8-bit Digital I/O, 9–35V DC wide voltage input and a cableless internal design, it is ready for harsh field conditions.
E-Life Inno-Box G3 1235U Rugged Box PC Intel Core i5-1235U 12th Gen mobile processor DDR4 memory (up to 64 GB), 128 GB NVMe SSD 2 × Intel Gigabit Ethernet, Wake on LAN 2 × RS232/485, 4 × RS232, 4 × USB 3.2 + 4 × USB 2.0 2 × HDMI display outputs, 8-bit Digital I/O Fanless enclosure, CE certified, 3-year warranty
The 12th Gen Intel Core i5-1235U (10 cores, up to 4.40 GHz, 12 MB cache) and Intel Iris Xe Graphics deliver high multi-core performance for edge applications.
The 128 GB M.2 PCIe Gen3 x2 NVMe SSD provides fast system access; 2 × 2.5” SATA bays offer additional storage. Memory can be expanded from 4 GB up to 64 GB.
The -20 ~ +60 °C operating range and fanless aluminum enclosure ensure reliable operation in cold storage, field cabinets and unheated areas.
Two BIOS-selectable RS232/485 ports and 4 × RS232, plus 4-in/4-out Digital I/O, enable direct integration with field devices and machine signals.
The 9–35V DC power input adapts to various cabinet and vehicle power systems, reducing the need for additional converters.
Windows 10/11 IoT and Linux support, dual HDMI outputs and Intel i210 + i219 Gigabit Ethernet with Wake on LAN offer flexible software and network setups.
The 12th Gen processor and NVMe storage meet the needs of projects seeking up-to-date performance in the compact Inno-Box family.
The wide temperature range, wide voltage input and cableless internal design provide durability in field and in-cabinet applications.
Windows IoT and Linux support gives you the freedom to choose the operating system that fits your existing application infrastructure.
The Inno-Box G3 1235U is offered under E-Life Solutions, the registered brand of Noya Tech. We define the memory, storage and operating system configuration together based on your project, test it with ISO 9001 and ISO 27001 certified processes and support it with our technical service in Türkiye.
Over 30 years of experience and a broad product range.
Assembly, testing and after-sales service in a 2,500 m² facility.
ISO 9001 quality and ISO 27001 information security.
Get pricing and lead time information for Inno-Box G3 1235U Rugged Box PC.
| Platform | |
|---|---|
| Processor | Intel Core i5-1235U, 10 cores, up to 4.40 GHz, 12 MB cache |
| Memory | 4 GB DDR4 SODIMM (max. 64 GB) |
| Storage | 128 GB M.2 PCIe Gen3 x2 NVMe SSD + 2 × 2.5” SATA bay |
| Graphics | Intel Iris Xe Graphics |
| Operating System | Windows 10/11 IoT, Linux |
| Connections | |
| LAN | Intel i210 + Intel i219 Gigabit Ethernet, Wake on LAN |
| Serial Port | COM1–2: RS232/485 (BIOS selectable), COM3–6: RS232 |
| USB | 4 × USB 3.2, 4 × USB 2.0 |
| Digital I/O | 8-bit, 4 inputs / 4 outputs |
| Video Output | 2 × HDMI |
| Expansion | M.2 Key E (Wi-Fi/4G) |
| Wireless | Optional Intel dual-band Wi-Fi + Bluetooth 4.2 |
| Mechanical & Power | |
| Enclosure | Aluminum, fanless, cableless internal design |
| Power Input | 9–35V DC (12V/5A adapter) |
| Dimensions | 205 × 125 × 70.5 mm |
| Weight | 1.5 kg |
| Operating Temperature | -20 ~ +60 °C |
| Certificate | CE |
| Warranty | 5 years |
No specifications match your search.
Compact Inno-Box models meet the need for a reliable computer that runs fanless and silently in confined spaces.
E-Life Inno-Box G3 1235U Rugged Box PC comes with a 5-year warranty, providing assurance for your long-term projects.
Email: info@noyatech.com
Phone: +90 850 399 66 92
Phone: +90 212 294 24 03
Our expert team is here to help with product selection, installation and integration questions. You can request the latest brochure, technical drawings and user manual from our team by quoting the product code.
It is compatible with Windows 10/11 IoT and Linux.
Thanks to its compact enclosure, it can be placed on a desktop, inside a control cabinet or on a machine body.
It runs on a wide 9–35V DC input range at ambient temperatures of -20 ~ +60 °C.
E-Life Inno-Box G3 1235U Rugged Box PC comes with a 5-year warranty.
